Description
Trolley Long Tube Respirator is a complete set of self-contained positive pressure air trolley breathing apparatus and composed of stainless steel trolley, carbon fiber cylinder, air supply tube, reducer, demand valve, full face mask, etc. It is continuous gas supply device. The user only needs to wear a mask, a supply valve and a gas supply long tube. The user can work without any body load. Vehicular long tube air respirator use two or four cylinders as gas source, we can replace any a cylinder without affecting its normal use, protective time is without limitation, which is especially suitable for used in tunnel, pipe or other limited space, and other contaminated environment for a long time difficult and comlicated work.
Features & Benefits
1. Continuous gas supply structure design, effective save time. Not effect work when replace air source in time.
2. Two people can work together for some hours only if has enough spare cylinders under the condition of all kinds of poisonous and harmful environment and lack of oxygen Equipped with a brake to prevent vehicle move by itself, it can be static in the 30 degree tilt the ground.
3. The main vehicle adopt high strength stainless steel pipe with no seal welding, strong and durable, stainless steel
4. trolleys, enhance corrosion resistance. Tube store in the roll barrel structure that is convenient for user. Tube is adopt Steel wire Of the super pressure
5. hose, long service life, tensile strength, not easy to curl, ventilation is smooth
6. According to client' s requirements equipped with escape device a custom tube length extended to 50 meters from cylinder valve to T-cock.
Applications:
- Chemical Industry
- Petroleum
- Metallurgy
- Steamship
- Medicine
- Coal gas
- Utilities
- Municipal Administration
- Storage
- Firefighting
- Rush to Deal With an Emergency
- Rescue
- Exploration
Main technical parameter
| ITEM | PART NUMBER | DESCRIPTION | MAIN MATERIAL |
| 1 | HY-YDGO-0I | Consist of : Trolley frame with two-wheeled fixed angle; Pneumatic arrangement; Regulator set; Hose_reel; Carrying case; |
Stainless Steel; Copper; |
| 2 | HY-YDGQ-02 | Extendable hose 50m, including main hose 30m & extension hose each 10m; | EPDM |
| 3 | HY-YDGQ-04 | Y-piece connection | Copper |
| 4 | HY-C-C06 | Carbon fiber composite cylinder | Aluminum liner, Carbon fiber, |
| 5 | HY-PF-01 | Cylinder valve | Copper |
| 6 | HY-MZ-01 | Full face mask | pc; EPDM |
| 7 | HY-GOF-01 | Demand valve | pc; EPDM |
